PS150 BOOST-330 Solar Surface Pump System
System Overview
- Head max. 160 ft
- Flow rate max. 5.7 USG/min
- Control inputs for dry running protection, remote control etc.
- Protected against reverse polarity, overload and over temperature
- Integrated MPPT (Maximum Power Point Tracking)
- Battery operation: Integrated low voltage disconnect
- Power max. 0.30 kW
- Input voltage max. 50 V
- Optimum Vmp* > 17 V
- Motor current max. 18 A
- Efficiency max. 98 %
- Ambient temp. -22...122 °F
- Enclosure class IP54
- Maintenance-free brushless DC motor
- Premium materials, stainless steel: AL/AISI 304
- No electronics in the motor
- Rated power 0.54 HP
- Efficiency max. 92 %
- Motor speed 280...1,750 rpm
- Insulation class F
- Enclosure class IPX4
- Water temperature max. 176 °F
- Suction head max. 10 ft
